Anderson Wright refines electrical reactor design by dedicated design software, and provides customers with tailor-made products. Iron core of electrical reactors is made of pressed and overlapped high-precision silicon steel sheet to avoid inductance difference between the three phases and ensure tuning precision of the electrical reactors. In addition, in a power grid environment with serious harmonic pollution, sufficient iron core linearity may withstand repetitive switching of capacitor groups and prevent saturation.
- Reactance rate （6%, 7% or 14%）
- Rated voltage of compatible capacitor：480V or 525V
- Noise：≤50dB
- Inductance error：±3%
- Insulation grade：H
- Linearity：when Ilin=1.2×（I1+ I2+……+ In-1+ In）=1.2×ΣI, attenuation of inductance shall not exceed 4% of rated inductance
- Overload capacity：1.8×In （or to be designed based on data provided by customers）
- Linearity：2.0×In
- Low losses
- Vacuum impregnation
- Standard：designed, manufactured and tested in accordance with IEC60289
- Indoor application
- No installation at a place with an elevation of more than 2000m （other specifications may be tailor made）
- No material that may have an impact on insulation or combustible and explosive material shall be placed around the place where the devices are installed.
- Excellent ventilation conditions shall be provided when the devices are installed in a cabinet.
- Interval between any two installed devices shall be >5cm horizontally and >12cm vertically.
