Power factor controller
AW-PQC power factor controllers are a new generation of control devices launched by Anderson Wright for data collection, reactive compensation, measurement of power parameter, and equipment operation monitoring.
- LED display
- May measure and display reactive parameters of the four quadrants, and monitor whether the reactive is capacitive or inductive
- May display application status of compensation equipment
- Refined control strategy, minimizes switch operations of capacitors
- Diversified switch programmes; regulation precision may be set based on actual requirements
- Main parameters of power distribution system may be viewed in operation mode
- Applicable to 50Hz or 60Hz power supply or distribution networks
- RS485 communication interface optional
- Not influenced by CT polarity or phase sequence
- Supply voltage：88～130/185～265/320～460V
- Sampling voltage: AC 100V±20％; AC 220V±20％; AC 380V±20％
- Sampling curren: AC 0～5A and 0～1A
- Power： ≤12VA
- Elevation： ≤2000m
- Input delay： 1～999s
- Manual/automatic control
- Operating temperature： -25℃～65℃
- All alarm contact and alarm record function
- Electrical safety and low voltage
- Standard: anti-interference performance meets requirements of IEC61000-6-2
- Electromagnetic radiation performance meets requirements of IEC61000-6-4
